How To Add Color Swatches [Dawn 15.1.0]

Step 1: Add code in settings_schema.json

Add the following code in settings_schema.json

{
    "name": "Color Swatches by WebSensePro",
    "settings": [
      {
        "type": "paragraph",
        "content": "Support WebSensePro by [Subscribing our Channel](https:\/\/youtube.com\/@websensepro?sub_confirmation=1)"
      },
      {
        "type": "text",
        "id": "optionName",
        "label": "Swatch option name",
        "default": "Color",
        "info": "Make sure capitalization is same as variant for e.g Color not color "
      },
      {
        "type": "paragraph",
        "content": "If your store is in different languages, type in all the different words and separate them with commas. For example: Color, Colour, Couleur"
      },
      {
        "type": "select",
        "id": "swatchType",
        "label": "Swatch type",
        "options": [
          {
            "value": "color",
            "label": "Color"
          },
          {
            "value": "variantImage",
            "label": "Variant image"
          }
        ],
        "default": "color"
      },
      {
        "type": "textarea",
        "id": "swatchColors",
        "label": "Colors",
        "placeholder": "Red:#ff0000\nGreen:#00ff00\nBlue:#0000ff",
        "default": "Black:#000000\nWhite:#f5f5f5\nBlue:#005eff\nRed:#c9002c\nPink:#ffd5e6\nBrown:#a2896b\nOlive:#808000\nGreenRed:#008000#c9002c\nGreenRedBlue:#008000#c9002c#005eff",
        "info": "One rule per line. Example: Blue:#005eff\n2 Color Swatch Example: GreenRed:#008000#c9002c\n3 Color Swatch Example: GreenRedBlue:#008000#c9002c#005eff"
      },
      {
        "type": "paragraph",
        "content": "You can also add [image files](\/admin\/content\/files?selectedView=all&media_type=Image) instead of using colors, in lowercase with spaces replaced by hyphens. Example: Green kaki: green-kaki.png"
      },
      {
        "type": "select",
        "id": "swatchStyle",
        "label": "Swatch style",
        "options": [
          {
            "value": "round",
            "label": "Round"
          },
          {
            "value": "square",
            "label": "Square"
          },
          {
            "value":"square-round-corners",
            "label":"Square round corners"
          },
          {
            "value": "portrait",
            "label": "Portrait"
          }
        ],
        "default": "round",
        "info":"Portrait mode is only available for the variant image type."
      },
      {
        "type": "range",
        "id": "swatchSize",
        "min": 20,
        "max": 120,
        "step": 2,
        "unit": "px",
        "label": "Swatch size",
        "default": 40
      }
    ]
  },

Step 2: Replace Code in product-variant-picker

Please replace the code on line 46 of the file named “product-variant-picker.liquid”:

<fieldset class="js product-form__input product-form__input--pill">
          <legend class="form__label">{{ option.name }}</legend>
          {% render 'product-variant-options',
            product: product,
            option: option,
            block: block,
            picker_type: picker_type
          %}
        </fieldset>

With the following code:

<fieldset class="js product-form__input product-form__input--pill add-new">
          <legend class="form__label">{{ option.name }}</legend>
          {% render 'product-variant-options',
            product: product,
            option: option,
            block: block,
            picker_type: picker_type
          %}
        </fieldset>

        <fieldset class="js product-form__input product-form__input--pill">
            {%- liquid
                assign optionNames = settings.optionName | split:","
                assign useColor = false
                for optionColor in optionNames
                  if optionColor == option.name
                      assign useColor = true
                      break
                  endif
                endfor
            -%}
          {%- if useColor -%}
             <legend class="form__label ">{{ option.name }}:<span id="selected-{{ option.name }}"> {{ option.selected_value }}</span></legend>
              {% render 'color-option', product: product, option: option, block: block %}
              {%- else -%}
             <legend class="form__label">{{ option.name }}</legend>
          {% render 'product-variant-options',
            product: product,
            option: option,
            block: block,
            picker_type: picker_type
          %}
          {%- endif -%}
          </fieldset>

Step 3: Create A New Snippet File

Create new snippet file color-option.liquid

{% comment %}
  Renders product variant options

  Accepts:
  - product: {Object} product object.
  - option: {Object} current product_option object.
  - block: {Object} block object.


  Usage:
  {% render 'product-variant-options',
    product: product,
    option: option,
    block: block
  %}
{% endcomment %}
{%- liquid
  assign variants_available_arr = product.variants | map: 'available'
  assign variants_option1_arr = product.variants | map: 'option1'
  assign variants_option2_arr = product.variants | map: 'option2'
  assign variants_option3_arr = product.variants | map: 'option3'

  assign product_form_id = 'product-form-' | append: section.id

  assign swatchType = settings.swatchType
  assign swatchStyle = settings.swatchStyle
  assign swatchSize = settings.swatchSize
  assign swatchColors = settings.swatchColors | newline_to_br | split: '<br />'

-%}

<style>
.product-form__input input[type='radio'] + label.color-swatch,
.product-form__input input[type='radio'] + label.color-swatch:after,
.product-form__input input[type='radio'] + label.color-swatch:before{
        border-radius: 0;
}
.product-form__input input[type='radio'] + label.color-swatch.round,
.product-form__input input[type='radio'] + label.color-swatch.round:after,
.product-form__input input[type='radio'] + label.color-swatch.round:before{
    border-radius: 100%;
  }
.product-form__input input[type='radio'] + label.color-swatch.round-corners,
.product-form__input input[type='radio'] + label.color-swatch.round-corners:after,
.product-form__input input[type='radio'] + label.color-swatch.round-corners:before{
        border-radius: 5px;
  }
  .product-form__input input[type='radio'] + label.color-swatch{
    border:1px rgb(214,214,214) solid;
    width: {{swatchSize}}px;
    height: {{swatchSize}}px;
    background-repeat: no-repeat;
    background-position: center;
    background-size: cover;
    margin-right: 9px;
  }
  .product-form__input input[type='radio'] + label.color-swatch:before{
    content: "";
    position: absolute;
    top: -1px;
    left: -1px;
    width: calc(100% + 2px);
    height: calc(100% + 2px);
    border: 1px rgb(214,214,214) solid;
    z-index: 0;
  }
  .product-form__input input[type='radio'] + label.color-swatch:after{
    content: "";
    position: absolute;
    top: 0;
    left: 0;
    width: 100%;
    height: 100%;
    z-index: 1;
    {%- if settings.dark or swatchType == "variantImage" -%}
       border: none;
    {%- else -%}
      border: 3px rgb(255 255 255) solid;
    {%- endif -%}
  }
  .product-form__input input[type='radio'] + label.color-swatch:hover:before{
    border: 1px rgb(125 124 124) solid;
  }
  .product-form__input input[type='radio']:checked + label.color-swatch:before{
  {%- if settings.dark -%}
    box-shadow: 0 0 0 2px rgb(var(--color-foreground));
    {%- else -%}
    box-shadow: 0 0 0 1px rgb(var(--color-foreground));
    {%- endif -%}
    border-color:rgb(var(--color-foreground));
  }
  .product-form__input input[type='radio'] + label.color-swatch.variant-swatch{
    background-color:white;
    {%- if swatchStyle == "portrait" -%}
    height: calc({{swatchSize}}px/ 0.66);
    {%- endif -%}
  }
.add-new{
  display: none !important;
}

.product-form__input input[type='radio'].add-new-class + label.color-swatch {
    border: 2px solid black;
}</style>

{%- for value in option.values -%}
  {%- liquid
    assign option_disabled = true

    for option1_name in variants_option1_arr
      case option.position
        when 1
          if variants_option1_arr[forloop.index0] == value and variants_available_arr[forloop.index0]
            assign option_disabled = false
          endif
        when 2
          if option1_name == product.selected_or_first_available_variant.option1 and variants_option2_arr[forloop.index0] == value and variants_available_arr[forloop.index0]
            assign option_disabled = false
          endif
        when 3
          if option1_name == product.selected_or_first_available_variant.option1 and variants_option2_arr[forloop.index0] == product.selected_or_first_available_variant.option2 and variants_option3_arr[forloop.index0] == value and variants_available_arr[forloop.index0]
            assign option_disabled = false
          endif
      endcase
    endfor
  -%}

  {%- if block.settings.picker_type == 'button' -%}
    <input
      type="radio"
      id="{{ section.id }}-{{ option.position }}-{{ forloop.index0 }}"
      name="{{ option.name }}"
      value="{{ value | escape }}"
      form="{{ product_form_id }}"
      {% if option.selected_value == value %}
      class="add-new-class"
  {% endif %}
    >
    {%- if swatchType == "variantImage" -%}
      <label
      data-{{ option.name }}="{{value}}"
      style="background-image:url(
      {%- liquid
        assign optionIndex = option.position | minus: 1
        for variant in product.variants
            if variant.options[optionIndex] == value
              assign swatchSizePortrait = swatchSize | times: 2
              echo variant.image | image_url: width: swatchSizePortrait
              break
            endif
        endfor
    -%}
       );"
       class="color-swatch variant-swatch {% case swatchStyle %}{% when "round" %}round{% when "square-round-corners" %}round-corners{% endcase %}"
          for="{{ section.id }}-{{ option.position }}-{{ forloop.index0 }}">
      <span class="visually-hidden">{{ 'products.product.variant_sold_out_or_unavailable' | t }}</span>

    </label>
    {%- else -%}
        {%- liquid
        for colorData in swatchColors
            assign colorDataArr = colorData | split:":"
            assign ruleName = colorDataArr[0] | strip
            if value == ruleName
                assign colorCodes = colorDataArr[1] | strip | split :"#"
                assign colorNumber = 0 | plus: colorCodes.size
                break
            endif
        endfor
    -%}
    <label
      data-{{ option.name }}="{{value}}"
      style="
    {%- case colorNumber -%}
        {%- when 2 -%}
            background-color: #{{ colorCodes[1] }}
        {%- when 3 -%}
            background: linear-gradient(135deg, #{{ colorCodes[1] }} 50%, #{{ colorCodes[2] }} 50%);
        {%- when 4 -%}
            background: linear-gradient(to right,#{{ colorCodes[1] }} 33%,#{{ colorCodes[2] }} 33%,#{{ colorCodes[2] }} 66%, #{{ colorCodes[3] }} 66%);
        {%- else -%}
            background-image:url({{ colorCodes[0] | downcase | replace: ' ', '-' | file_img_url }})
        {%- endcase -%}
        ;"class="color-swatch {% case swatchStyle %}{% when "round" %}round{% when "square-round-corners" %}round-corners{% endcase %}"
        for="{{ section.id }}-{{ option.position }}-{{ forloop.index0 }}">
      <span class="visually-hidden">{{ 'products.product.variant_sold_out_or_unavailable' | t }}</span>
    </label>
    {%- assign colorCodes = "" -%}
    {%- endif -%}
  {%- elsif block.settings.picker_type == 'dropdown' -%}
    <option
      value="{{ value | escape }}"
      {% if option.selected_value == value %}
        selected="selected"
      {% endif %}
    >
      {% if option_disabled -%}
        {{- 'products.product.value_unavailable' | t: option_value: value -}}
      {%- else -%}
        {{- value -}}
      {%- endif %}
    </option>
  {%- endif -%}
{%- endfor -%}

<script>
  document.querySelectorAll('input+label[data-{{ option.name | downcase }}]').forEach(el=>{
    el.addEventListener('click',()=>{
      document.querySelector('#selected-{{option.name}}').textContent = " "+el.getAttribute('data-{{ option.name | downcase }}')
    })
  })
</script>
